2008 Honda Shadow Spirit 750
Honda Shadow Spirit 750 C2
| Make Model | Honda VT 750C Shadow Spirit |
| Year | 2008 - 09 |
| Engine | Four stroke, 52�V-twin, SOHC. 3 valve per cylinder |
| Capacity | 745 cc / 45.7 cu-in |
| Bore x Stroke | 79 x 76 mm |
| Cooling System | Liquid cooled |
| Compression Ratio | 9.6:1 |
| Induction | Two 36mm diaphragm-type CV |
| Ignition | Solid-state with electronic advance, two spark plugs per cylinder |
| Starting | Electric |
| Max Power | 43 hp / 32.1 kW @ 5500 rpm |
| Max Torque | 60.5 Nm / 44 ft.-lb @ 3000 rpm |
| Transmission | 5 Speed |
| Final Drive | Shaft |
| Front Suspension | 41mm Telescopic fork. |
| Front Wheel Travel | 129.5 mm / 5.0 in |
| Rear Suspension | Dual shocks 5-way spring-preload adjustability |
| Rear Wheel Travel | 90 mm / 3.5 in |
| Front Brakes | Single 296 mm disc 2 piston caliper |
| Rear Brakes | 180 mm Drum |
| Front Tyre | 90/90 �17 |
| Rear Tyre | 160/80 �15 |
| Wheelbase | 1615 mm / 63.6 in |
| Seat Height | 700 mm / 27.6 in |
| Dry Weight | 229 kg / 504.9 lbs |
| Fuel Capacity | 14 Litres / 3.7 US gal |
The sportiest cruiser with a 21-inch front wheel and low 25.7-inch one-piece gunfighter seat, the Shadow Spirit 750 C2 exudes street-rod style with handling, comfort and quality levels only Honda can put together.
Features & Benefits
- A 21-inch front wheel for a narrow, custom look and light steering feel.
- Sleek one-piece gunfighter-type seat.
- Newly designed handlebar offers sporty, street-rod feel.
- New custom, integrated taillight design.
- Sleek two-into-two exhaust system features bullet-style mufflers for a classic street-rod style.
- Incredibly low 25.7-inch seat height.
- Shaft final-drive system provides smooth and reliable low-maintenance operation.
- New colors include Ultra Blue Metallic, Black/Flame, Red/Flame and Black.
Unique Features
- Big-bike looks and feel at a very attractive price.
- Classically styled headlight.
- Tank-mounted speedometer features attractive chrome instrument housing.
Engine/Drivetrain
- 745cc liquid-cooled V-twin engine produces impressive power over a broad rpm range.
- Crankshaft features long-stroke design along with high-mass ACG to produce strong V-twin feel and low-rpm torque peak.
- Single 34mm constant-velocity (CV) carburetor offers crisp throttle response.
- Three-valve cylinder-head design utilizes two spark plugs per cylinder for excellent combustion efficiency and high power output.
- Finned cylinders enhance appearance and give a big-bike look.
- Aluminum radiator maintains consistent engine temperature for optimum performance and long engine life. Mounted between frame rails for enhanced appearance.
- Wide-ratio five-speed transmission.
- Reliable electric starting system.
- CD ignition with electronic advance offers dependability and is maintenance-free.
- Air-injection system reduces emissions by injecting air into the exhaust ports to ensure complete combustion.
SUSPENSION
- Innovative frame design features large, steel tube backbone reaching back from cast steering head to rear of the engine case for simplicity and strength.
- Sturdy and responsive 41mm front fork features large-diameter chrome-steel shrouds and large billet-aluminum triple-clamp for a distinctive retro look. Delivers confident, neutral handling and plush 4.6-inch wheel travel.
- Large 4mm-thick fork brace mounted under fender enhances rigidity.
- Dual-shock rear suspension features five-position spring preload adjustability and eye-catching chrome covers, while offering 3.5 inches of wheel travel for a smooth ride.
- Single front disc brake with twin-piston caliper grips a 296mm drilled rotor between sintered metal pads. Rear brake is drum type.
- Shaft final-drive system provides smooth and reliable low-maintenance operation.
- Speedometer is set into the front of the fuel tank for classic retro styling.
Additional Features
- Tank-mounted speedometer features attractive chrome instrument housing.
- Instrument lights mounted inside meter for optimum visibility.
- Chrome highlights include cylinder-head cover, air-cleaner cover, left and right engine sidecovers, brake and clutch lever brackets, rear brake pedal, shift lever, swingarm pivot cap, ignition switch cover, handlebar, rear shock covers and headlight.
- Solid aluminum footpegs with wide rubber trim bands project a custom-made look.
- Handlebar is positioned low and wide for a comfortable feel and is mounted on rubber-cushioned risers to reduce vibration.
- Broad, low-slung solo seat with detachable passenger seat.
- Stylish 3.7-gallon fuel tank.
- Brilliant, 60-/55-watt halogen headlight.
- Large, custom-styled taillight and attractive retro-styled turn indicators.
- Steering-head lock and helmet lock for added security when parked.
- Transferable one-year unlimited-mileage limited warranty; extended coverage available with a Honda Protection Plan.
- Purchase of a new, previously unregistered Honda unit by an individual retail user in the United States qualifies the owner for a one-year complimentary membership in the Honda Rider's Club of America� (HRCA�). Benefits include roadside assistance, online access to the Honda Common Service Manual, six issues of the bimonthly Honda Red Rider� magazine, travel discounts, trip routing and MSF reimbursement, plus access to the HRCA Web site (www.hrca.honda.com). For details on the HRCA, dealers should call (310) 783-3958, 8:30 a.m. to 5 p.m. Pacific Time.
Available accessories
- Touring Accessories: Custom Windscreen, Lower Wind Deflector, Leather Saddlebags (three styles: Studded, Fringed and Plain), Synthetic Leather Saddlebags, Leather Tank Belt (Studded and Plain), Leather Front Pouch (three styles: Studded, Fringed and Plain), Leather Touring Bag (three styles: Studded, Fringed and Plain), Saddlebag Liner Set.
- Chrome accessories: Light Bar, Spotlight Visors, Backrest with Pad (available in Tall and Low styles), Backrest Trim (available in Tall and Low), Rear Carrier (Square-Tube), Passenger Grabrails, Radiator Guard, Allen-Bolt Inserts (three sizes: 5mm, 6mm and 8mm), Throw-over Saddlebag Supports, Driveshaft Cover.
- Billet accessories: Master-Cylinder Cap (four styles: Fluted, V Design, Neo-Retro and Chrome), Handlebar Clamps, Swingarm Pivot Cover Set, License-Plate Frame (three styles: Fluted, V Design and Neo-Retro).
- Additional accessories: Cycle Cover.
(Accessory availability and specifications subject to change without notice.)
